Mobile Batching Plant

Mobile Batching Plant
Mobile Batching Plant
Send Inquiry
Product Code : 05
Brand Name : Aquarius
Product Description

Leveraging on our vast industry experience, we bring forth for our clients a qualitative range of Mobile Concrete Batching Plants. Featured with an energy efficient air compressor pump, these batching plants are offered in varied designs, models and specifications; that worth  varied compacted concrete output per cycle. Post production, our team of quality controllers checks these plants on various parameters to ensure their flawlessness. These batching plants possess the ability to accommodate four different types of materials likely aggregates, cement, fly ash and water; and two types of chemical additives. Offered Mobile Batching Plants are widely known for the below mentioned properties:

  • Simpler operations
  • Longer working life
  • High efficiency
  • Low maintenance


AQUARIUS has launched two new plants MP 21 and MP 24.

The final technology mobile plants, escalated on reusable pre-cast bases. The base can be raised and transferred to another area. It comes with Planetary Mixer of 0.5 m3 compressed yield per batch as well as dual Shaft Mixer of 1.0 m3 compressed output per batch.

It holds 4 types of collectives, 2 types of cement, fly ash, 2 types of chemical preservatives, clean water and used water.

The dense design improves the production capability and fits in thin plot ranges. It is offered with 2 levels of control system with straight characteristics built in for outworkers and ready-mix producers.

Salient Features:

  • Drive through plan for amplified productivity
  • Escalated on re-usable pre-cast basis, which can be transferred to other sites effortlessly
  • Obtainable with 0.5 cubic meter batch size Planetary Mixer and above 1 cubic meter dual Shaft Mixer
  • Carry reliable class concrete and are mainly favored in the RMC industry
  • 4 Aggregate section Bins with an overall storage capability of 30/50/70 cubic meter
  • Elevated accuracy load cells for self regulating electronic weighing of cement, aggregates & water with digital demonstration
  • 2 level PLC based control system with real-time SCADA for control and data management, RT - MATIC PLUS / RT SMART
  • Compressed design that enhances fits in restricted or limited areas
  • Less in operation & repairs cost
  • Lowest amount aggregate packing height
  • Strong structure with ridged bins
  • Huge mixer stage for easiness of repairs
  • Additional security with twofold wire rope for skip
  • Direct cabin included in standard scope

AQUARIUS Mobile Plants unswervingly release the concrete into a Transit Mixer. The units are escalated on re-usable pre-cast bases, which can be transferred to another site effortlessly. It is obtainable with 0.5 m3 Planetary Mixer, 1 m3 and 1.25 m3 identical Shaft Mixers, with an hourly fabrication of 30 m3, 60 m3 and 70 m3 per hour. The Mobile Plants are offered with 4 Aggregate Bins with an overall storing capability of 20 cubic meters. With elevated accuracy load cells for electronic weighing of cement, aggregates & water and a digital display, the MP series units are the most packed in mobile batching units from AQUARIUS variety of goods.

Another trait is the Skip Hoist agreement for mixer loading and a modular, 2 levels PLC based control method with real-time SCADA for control and information management, RT-MATIC PLUS. These units have a compressed design that increases the manufacturing capability and adjusts in lesser plot sizes.

An Admixture Dosing Unit and a standard Cement Screw Conveyor too is a branch of the criterion offering. A extremely reduced operation & repairs cost and a probable incessant production cycle as small as seconds make the MP Series Plants the most favoured plants in the Contractor & RMC division.

The new plants Mp 21 and MP 24 have been fabricated by accepting the needs of the undersized sites which do not require concrete production rate as elevated as 30 m3 per hour but fitting and transferring time needed is minimal possible. Keeping most of the characteristics of finest size plants like drive through plan for transportation mixer loading, belt weighing for collectives, autonomous cement and water evaluating systems, PLC and SCADA basis control system etc. the new forms are furnished with 0.35 m3 and 0.375 m3 compressed yield batch size for optimal usage of the tools. Thanks to the compressed plan these plants fit in lesser plot size. Alike to their big brothers in this type, these plants also do not require any everlasting bases but only re-usable pre-cast bases for mixer construction and PCC for collective storage bins. The units are presented with 4 sections for the collective storage bins with a very small stacking height. Elevated accuracy load cells and electronic evaluating systems making sure batching accuracy.

The control cabin for these units is located on peak of the mixer structure, offering the operator a seal and simple sight of the unit actions and a great sight of all the deeds like transportation mixer movement, collective loading, concrete outcome from mixer etc and also reducing dust irritation. PLC and PC based control system is another emphasize in this type. SCADA based system with all probable data examination, remote aid, data in Excel format, utilization records, alarms and online assistance etc make this plant nothing lower than the elevated end plants.

These units are capable of with planetary mixers which is a distinctive trait in this range. Planetary mixers clearly make sure quick and uniform mixing in minimum possible time with very small operating costs in this size.

Other Details:

We are occupied in presenting Mobile Batching Plants to our end users. Mobile Batching Plants is an inventive, modified concrete manufacture answer for outworkers. Skid escalated unit with planetary mixer. Mobile Plants -MP are obtainable with diverse compressed concrete yield per cycle.

Mobile plants -MP

It can adjust 4 types of collectives, cement, fly ash, water and 2 types of chemical preservatives. No foundations needed. It has Quickest dismantling, transferring and commissioning at another site. High-tech control system fabricated for in house concrete production.


  • MP 19
  • MP 21
  • MP 30
  • MP 60
  • MP 70
  • MP 90
